r100gs front brake improvement

[B Murr]

I have a 93 GS with the floating disk , and finding and fitting HH pads made a decent improvement for a small additional outlay over replacing with stock.

However , I paid around $28- to HPM for a nicely made adapter to take the six pot Tokico caliper found on a few turn of the century Kawasukis, and cheap and easy to find.

HPM is a vendor on the Adventure Riders forum.

With a set of EBC HH 102 pads in the new caliper there is a nice step up from the twin pot Brembo, for a modest outlay.

For around $100- I have a brake which has no trouble locking the tire, and I dont need any more than that.

Do you have any pics of that set up beemerboff?



[Paul Rochdale]

My take on the poor front brake saga is -

R100GS-PD standard single piston brake caliper - dire
Modified K100 twin pot caliper - poor
stainless steel brake pipes - not brilliant.
Floating steel brake disc - barely safe.

Next step?



[cookie]

My take on the poor front brake saga is -

R100GS-PD standard single piston brake caliper - dire
Modified K100 twin pot caliper - poor
stainless steel brake pipes - not brilliant.
Floating steel brake disc - barely safe.

Next step?

R100GS-PD standard twin piston brake caliper on bigger disc - sort of OK.



[Colt]

next step,how about a
bigger floating disc? or a 6 pot billet harrison?



[John Armstrong]

Next step?

Money no object? How about: http://www.spiegler.de/en/products/brake-systems/bmw-brake-improvement

Is there a recommended stainless pipe maker for the front to go from the master cylinder to the caliper?



[Solo Lobo]

Throwing on a Nissin 6 piston caliper requires a bit of machining, but can typically be done on the cheep and uses the stock rotor...

http://www.advrider.com/forums/showthread.php?t=75031&highlight=nissin



[Redboots]

Money no object? How about: http://www.spiegler.de/en/products/brake-systems/bmw-brake-improvement

Is there a recommended stainless pipe maker for the front to go from the master cylinder to the caliper?

Obvious answer is Spiegler

I had a Spiegler disk and 4 pot calliper on the GSPDC that I have now. I would not say it was any better than the HE 320mm rotor and HE 4 pot calliper.
I think the Speigler disc is of a standard size. I put it on my old bike before I sold it Kept the HE setup.

John



[John Armstrong]

Obvious answer is Spiegler

I had a Spiegler disk and 4 pot calliper on the GSPDC that I have now. I would not say it was any better than the HE 320mm rotor and HE 4 pot calliper.
I think the Speigler disc is of a standard size. I put it on my old bike before I sold it Kept the HE setup.

John

I think the Speigler pipe won't be a budget option given that the full fat improvement set up costs €799

And you say it's no better than the "budget" €225 disc and rotor or €395 for the disc, and 4 pot caliper



[Redboots]

I think the Speigler pipe won't be a budget option given that the full fat improvement set up costs €799

Bugger... maybe I should have kept it

And you say it's no better than the "budget" €225 disc and rotor or €395 for the disc, and 4 pot caliper

I'm quite happy with the HE disk/caliper. Feels like there is as much braking as I need. If I want more, he does 3, I think, grades of pads. I've gone for the long-lasting

You can find "Lucas Bremsleitung" on ebay de for about €50... dunno how that compares....

John

John



[John Armstrong]

Venhill etc cost about £25 in the UK, whereas Euro land seem to be at least €50

The main query I guess is the lower bit, to replace the solid pipe onto the caliper, and the fittings that is needed.

At present I've got a semi floating caliper, with HH sintered pads, stainless braided upper and solid lower pipes



[cookie]

i found i needed a slightly longer solid pipe making up to reach the relocated caliper with the HE kit. not essential, but looks less bodgy IME.

i also think retaining the solid pipe looks neater than weaving the hose around the fork leg, but that's just me



[Redboots]

The main query I guess is the lower bit, to replace the solid pipe onto the caliper, and the fittings that is needed.

Personally, I don't like the flexi all the way to the calliper. I think it looks crap and "looks" vulnerable inside the fork leg. So a nice steel pipe is what I have. You can get one made up for next to nowt.
I looks like a "proper job" having the pipe. IHMO of course

Stiffy

Semi

John



[John Armstrong]

See what you mean, a stiffy is better than a floppy one



[JPR]

Money no object? How about: http://www.spiegler.de/en/products/brake-systems/bmw-brake-improvement

Is there a recommended stainless pipe maker for the front to go from the master cylinder to the caliper?

Hi John
Ive recently done the conversion to a six pot Tokico using the HPM adaptor.
For the brake line I went to JLS Motorsport AKA James Lister & Sons Union Street West Bromwich.Biker friendly outfit,theyll make up anything you want,on the spot.Even the fancy coloured ones.
I had a 40 inch brake line,banjo bolts banjos,all in stainless.
Tellem your trade ,get 40% off.Cost me just a tad over £20.
Took about 10 mins to knock up.
JPR



[JPR]

Hi John
Ive recently done the conversion to a six pot Tokico using the HPM adaptor.
For the brake line I went to JLS Motorsport AKA James Lister & Sons Union Street West Bromwich.Biker friendly outfit,theyll make up anything you want,on the spot.Even the fancy coloured ones.
I had a 40 inch brake line,banjo bolts banjos,all in stainless.
Tellem your trade ,get 40% off.Cost me just a tad over £20.
Took about 10 mins to knock up.
JPR

Had a senior moment,the adaptors the Harisson Precision jobby as per Adv Riders
